不锈钢大骨头粉碎机(CE)
Big Bone Crusher ( made of stainless steel )
( CE )
成品粒度/Partical size:12 -50 mm
高效的连续进出料设计
Designed for continuous operation and for a high efficiency
刀具表面硬度处理以延长使用寿命
hard faced knives and anvils for a long durability
单轴或双轴设计可选
one shaft or two shaft design
1. 概述( Description ):
不锈钢大骨头破碎机一般用于猪骨、牛骨、马骨、驴骨等动物大骨头的第一道破碎,将动物撕碎成小块状,在进入后道破碎。
Stainless big bone crusher is normally used for the first crush step of animal such as pig , Cattle , hose , donkey , etc … , after crushed into small pieces then feed into next crush step .
不同原材料的连续破碎
raw or fine continuous size reduction of different materials
鼓式破碎机也可用于精细造粒
a drum crusher can be also used for a fine granulation
这些重载破碎机主要被设计作为动物整体的第一步破碎机,骨头和各种各样的生物垃圾。
these hard work crushers are primary designed as a first stage at rendering plants for a processing of animal by-products as whole carcasses , bones and all sorts of biological waste
破碎机也可以用于公共废物造粒(木材,稻草,玻璃,硬塑料等)。
the crusher can be used also for a communal waste granulation (wood,straw ,glass,hard plastics ,etc.)
高效的设计最少的维护
Efficient design for a minimum maintenance
易于更换破碎刀的设计
Construction for an easy replacement of the knives
辅助设备/Accessories:
原料提升机raw material elevators
出料螺旋输送机或者带输送泵或者用气力输送
discharge screw conveyors or with pumps or by pneumatic conveyors
支撑框架supporting frame平台platform
含软启动的电机motor with soft - start进料滑槽和出料漏斗inlet and outlet chutes
设备材质/Construction Material:
物料接触处不锈钢制作,外部支撑框架碳钢喷砂喷漆制作,外封不锈钢
表面高硬度处理过的定刀和动刀
Crusher in contact with raw material made of stainless steel , carbon steel platform with sand blasted and painted , covered by stainless steel .
Special hard faced fixing and rotating knives .
型号 Model |
BC5 |
BC10 |
BC20 |
BC30 |
BC40 |
功率Power(KW) |
37 |
45 |
55 |
55 |
75 |
重量Weight(Kg) |
4100 |
5450 |
5910 |
6120 |
8020 |
产量Capacity(Kg/h) |
5000 |
10000 |
20000 |
30000 |
40000 |
外形尺寸Mesurement(LXWXH)(m) |
3.5X1.6X1.5 |
3.7X1.7X1.5 |
4.1X1.8X1.5 |
4.2X1.8X1.6 |
4.5X1.8X1.7 |
Note: customized equipment is acceptable for us .
CE & UL requirement is acceptable for us .
