不锈钢重锤式破碎机(CE)
Heavy Hammer Mill ( Made of Stainless Steel )
( CE Approved )
1. 概述( Description ):
不锈钢重锤式粉碎机广泛应用于制药工业,食品工业,化学,橡胶,电子工业等领域。
SS heavy hammer mill is a kind of mill widely used in pharmaceutical industry ,food industry , chemical industry, Rubber industry ,Electrical industry ,etc… .2. 原理( Principle ):
块状物料从粉碎机顶部均匀的加入,经过一个自关闭式门后,进入高速旋转的重锤粉碎区,重锤下面有筛网,网的孔径可选,小于孔径的物料穿过网孔排出粉碎机外,大于孔径的物料继续在内部被粉碎。当重锤高速旋转的时候,会产生正压,有气流产生,若用于固体粉碎,可能会产生粉尘,一个额外的除尘器需要安装在粗碎机的旁边,用来收集从粗碎机出来的粉尘。
Big briquettes being feed into the mill from the top inlet , there is a self-close door for protect material coming out once briquettes come in ,briquettes come into the high speed hammer area , a net under the hammer , the net hole size is selectable , material being crushed by high speed rotating hammer , the crushed material which size less than net hole can come out , other big briquettes was continuously crushed by rotating heavy hammer. when hammer rotating , some pressure and air flow generated ,if for crush solid material without moisture , one additional filter beside the mill for collect the dust from the outlet of mill is necessary .
3、应用范围( Application Scope )
适用于需要将原料破碎成颗粒,筛网的孔径一般在10 -35mm 。
It is suitable for the raw materials that need to be crushed into granules , the net size normally in10 to 20 mm
4、技术参数Technical parameter
型号规格 |
给料粒度 |
出料粒度 |
生产能力 |
电机功率(kw) |
总重量(t) |
外形尺寸 |
PCΦ400×300 |
≤200 |
adjustable |
5-10 |
4P 11-15 |
0.8 |
900×670×860 |
PCΦ600×400 |
≤250 |
adjustable |
10-22 |
4P 22-30 |
2.26 |
1200×1050×1200 |
PCΦ800×600 |
≤250 |
adjustable |
18-40 |
6P 45-55 |
4.8 |
1310×1180×1310 |
PCΦ1000×800 |
≤350 |
adjustable |
25-50 |
8P 75 |
5.9 |
1600×1390×1575 |
PCΦ1000×1000 |
≤350 |
adjustable |
30-55 |
8P 90 |
8 |
1800×1590×1775 |
Note: customized equipment is acceptable for us .
CE & UL requirement is acceptable for us .
