无重力混合机(CE)
No Gravity Mixer
(CE Approved)
1. 概述( Description ):
本系列混合机以强烈、高效混合为特点、卧式筒体内两根搅拌等速反向旋转,轴上特殊布置的桨叶确保物料径向、环向、轴向三向运动,形成复合循环,在极短的时间内达到均匀混合
This series machine takes a strong and high effective mixing as its features the two mixing axles rotate reversely at an identical revolution in the horizontal drum body. The paddles,specially distributed on the axle ensure that the material move radically, circulatingly, and axially, so as to from a compound motion, and in an extremely short time, the material is mixed evenly.
2. 特点(Features):
1、混合精度高,速度快,能耗低,可密封操作。
The equipment can run in an enciosure, with highprecision, high speed, low energy consumption.
2、气动、电动、手动出料方式
Pneumatical, electrical and manual discharging metod.
3、筒盖上可布置雾化装置以实现固液混合
The atomizing device can be distributed on the cylinder cover to realize the solid-liquid mixing.
3、应用范围( Application Scope )
化学药品、洗涤剂、涂料、树脂、玻璃硅、颜料、农药、化肥、饲料、饲料添加剂、小麦粉、奶粉、香料、微量成分、咖啡、食盐、砼添加剂、塑料及各种浆料、粉料的干燥与混合。
It is suitable for the drying and mixing of the following materials:chemicals, detergent, fertilizer, feedstuff, feedstuff additive wheat flour, milk power, perfume, micro ingredient, coffee, gourmet power, salt, plastic and all kinds of pulp, power material.
4、技术参数Technical parameter
型号规格Model | WZ-0.05 | WZ-0.1 | WZ-0.3 | WZ-0.5 | WZ-1 | WZ-2 | WZ-3 | WZ-4 | WZ-6 |
一次混合Capacity/batch kg | 24-30 | 40-60 | 120-180 | 200-300 | 400-600 | 800-1200 | 1200-1800 | 1600-2400 | 2400-3600 |
装机功率Motor kw | 2.2 | 3 | 4-5.5 | 5.5-7.5 | 7.5-11 | 11-15 | 18.5-22 | 22-30 | 30-37 |
设备重量Weight kg | 250 | 360 | 750 | 880 | 2100? | 2740 | 3800 | 5100 | 6200 |
